Máy khoan Aristech CNC
Máy khoan Aristech CNC
Khoan Aristech CNC
| SERIES NO. | SPECIFIC. | DNC-35 | DNC-50 |
| Work table (LxW) | mm/inch | 600×350 (23.6×13.8) | 700×450 (27.6×17.7) |
| Work tank (LxWxH) | mm/inch | 1000x650x100 (39.4×25.6×3.9) | 1160x935x100 (45.7×36.8×3.9) |
| X axis travel | mm/inch | 400 (15.7) | 650 (25.6) |
| Y axis travel | mm/inch | 300 (11.8) | 450 (17.7) |
| Ram servo travel Z1 | mm/inch | 250 (9.8) | |
| Work head Sparking travel W | mm/inch | 380 (14.9) | |
| Max.workpiece weight | kgs/lbs | 250 (550) | 300 (660) |
| Electrode pipe diameter | mm/inch | ø0.3-ø3.0 (0.020-0.118) | ø0.3-ø3.0 (0.020-0.118) |
| Mini./Max. heigh of workpiece | mm/inch | 50-300 (1.9-11.8) | |
| Outside dimension (LxWxH) | mm/inch | 1100x1300x2300 (43.3×51.2×90.6) | 1500x1700x2300 (59x67x90.6) |
| Packing dimension (LxWxH) | mm/inch | 1870x1450x2230 (73.7×57.1×87.8) | 1,590×1,790×2,230 (62.6×70.5×87.8) |
| Net Weight | kgs/lbs | 1200 (2640) | 1900 (4180) |
